Systemlow rig-set

useable as mini-low rig, side rig or high rig

The MovieTech system low rig allows low shot positions for the Camera. The height can be stepless adjusted. The differently support tubes can be used single or combined. The outer diameter of the support tubes is 80mm (2” 8’ inch).

The new System low rig-Set includes two offset-adapter with 80mm (2” 8’ inch) Euro mount clamping.

The Surface of the offset-adapter is provided with 25mm (10’ inch) drillings. The drillings are used for mounting of accessories, fex. Clamp bolt (seat arm bolt etc.). The accessories will be mounted by clamping with Maggot screws (sideways) or clamp bolts with a central clamping system (clamping via Allen key by spreading the mechanism)

A big advantage is the new counter weight bar, which can be placed different and it is traversable. If the bar is in the way during filming, it can be mounted quick and easy in different positions.

Product highlights

Technical data

Accessories

Item.No. 2087-01SET consisting of:

  • 3 hard coated aluminum tubes 300/400/765 mm
  • 1 Connecting tube
  • 1 out rigger 467mm (1″ 6′) with double euro mount adapter
  • 1 out rigger 547mm (1″ 10′) with double euro mount adapter
  • 2 end capes
  • 1 flange tube
  • 1 roll case
  • 1 end piece with euro mount
  • 1 clamp bolt
  • 1 hexagonal wrench

The highlights at a glance:
  • Numerous tube combinations possible
  • Different adapter included in the set
  • 25mm (10’ inch) drillings in the offset-adapter
  • Counter weight bar can be placed different and is traversable
Technical data:

Dimensions:

Boom 1: 467 mm/ length (1″ 6′)
Boom 2: 567mm/ width (1″ 10′)
Length tube 1: 300 mm/ width (12′)
Length tube 2: 400 mm/ height (1″ 4′)
Length tube 3: 765 mm/ height (2″ 6′)

Weight:

19.24 kg (42.42 lbs)

Technical drawing:

Accessories:

Item No. 2110 Counterweight 16 kg

Item No. 2111 Counterweight 10 kg

Item No. 2112 Counterweight 5 kg
