Electromechanical column

Electromechanical column for Magnum Dolly

Produced since 20 years while being continually developed further – the heart of the movement!
The electromechanical column for Magnum Dolly system !

Product Highlights

Technical data

Accessories

Item No. 2000-0 consists of:

  • Base dolly with integrated turnstile mount
  • base plate with Euro adapter
  • steering rod standard
  • combi-wheels (studio-/ track wheels)
  • 48V-motor with microprocessor control with self diagnostics and display, 4 stage ramp selector for Duo Jib or standard use, 4 separate programming channels. Integrated digital display for height, program position, program channel, selected ramp, error display.
    Integrated emergency back-up in column.
  • 2 batteries 24V with charge level indicator
  • hand control unit with cable, mains on/off switch
  • stage speed selector, function indicator
  • seat support
  • manual

Highlights:
  • precise and smooth column movements due to microprocessor control
  • allows to set low and high movement limit, store up to 30 points and whole column movements for an accurate reproduction of vertical movements
  • various speed and ramp settings selectable
  • column is removable for easy transport
  • NEW! The guide rails of the Magnum column are made of a new steel alloy that has a smoothing effect on the running of the column.

movietech-magnum-elektronik

Precision and reliability:
  • NEW! The new Magnum engine – the “heart” of the dolly is the result of sophisticated engineering and manufacturing techniques. The lifespan of the motor has been considerably extended and the silence of the motor has further been improved with its new low-noise brake.
  • NEW! The latest Magnum Dolly column is equipped with a new electronic unit. Together with the standard hand control and the wireless hand control that have also been updated, the control system matches the high requirements of the film set. We have achieved highest precision with optimal versatility.
movietech magnum dolly minijib
movietech-magnum-dolly-display

The display shows the current height of the column by three numbers and the energy consumption of the motor as well as the selected settings of program mode, ramp, speed.

movietech-magnum-dolly-panel

Via selection switch, program mode, ramp, speed up and down may be selected.

movietech-magnum-dolly-handregler
The compact hand control permits to easily control and program the column.
movietech-magnum-dolly-funkhandregler
Additionally, a radio controlled hand control is available as an accessory part.
Technical Data:

movietech-magnum-column-engl

Technical drawing:

400x400

Magnum Dolly with divisible column:

movietech-magnum-säule-montage

movietech-magnum-dolly-ubangi

DOWNLOAD Operating instructions, Service booklet and Coding data

Accessories:

Energy and testing device for Magnum Dolly system

MovieTech-accessories-24-volt-charging-station-complete-2-batteries

Item No. 2004-0SET 24V charging station complete for 2 batteries
built up of:
Charger adapter plate (Item No. 2004-0)
Magnum mains/charger unit 24/48V (Item No. 2002-0)

MovieTech-accessories-Magnum-Dolly-24Volt-battery-charger-level-indicator

Item No. 2003-0 Magnum 24V battery with charge level indicator

MovieTech-accessories-power-supply-box-230-volt

Item No. 2019-0 Power supply box 230V

MovieTech-used-equipment-test-device-for-hand-controler

Item No. 2014-0 Test device for hand control unit control (old version)
Item No. 2008-5000A Test device for hand control unit control (new version)

MovieTech-accessories-tester-24-volt-batteries

Item No. 2015-0 Tester for 24V batteries

MovieTech-accessories-bridge-plug-24-volt-operation

Item No. 2020-0 Bridge plug for 24V operation

Accessories Magnum Dolly operating elements

movietech-1002-basisplatte-mit-euroadapter

Item No. 1002-0 Base plate with Euro Adapter for Basic-Dolly

movietech-1003-basisplatte-mit-drehkreuz

Item No. 1003-SET Base plate with turnstile mount

Steering rod and accessories for Magnum Dolly system

movietech-magnum-lenker-verstellbar2_500x500

Item No. 1013-00 telescopic steering rod

movietech-magnum-lenker-lang-und-kurz

Item No. 1012-0 Steering rod Short
Item No. 1010-0 Steering rod Standard

MovieTech-accessories-hand-control-holder

Item No. 1040-0 Hand control holder

MovieTech-accessories-pan-bar-adapter-hand-control

Item No. 2013-0 Pan bar adapter for Magnum remote control

movietech-1020-0-lenkausleger

Item No. 1020-0 Magnum steer-out extension

Wheels for Magnum Dolly system

MovieTech-accessories-studio-wheels-soft-standard-x8-40-shore-80-shore

Item No. 1215-0SET Set of studio wheels, soft (8 pcs) 40 shore

MovieTech-accessories-studio-wheels-soft-standard-x8-40-shore-80-shore

Item No. 1216-0SET Set of studio wheels, standard (8 pcs) 80 shore

MovieTech-accessories-track-wheel-incl-axis-and-bearing

Item No. 1200-253SET Trackwheel incl. axle and bearing

MovieTech-accessories-set-of-pneumatic-wheels-x8-magnum-dolly

Item No. 1210-0SET Set of pneumatic wheels (8 pcs)

Accessories Magnum Dolly operating elements

MovieTech-accessories-Magnum-Dolly-column

Item No. 2000-0 Magnum Dolly 48V column

movietech-magnum-dolly-funkhandregler

Item No. 2089-01 Magnum radio hand control

MovieTech-accessories-magnum-dolly-dust-cover-column

Item No. M2005 Dust cover for Magnum Column

MovieTech-accessories-rain-dust-cover-magnum-dolly

Item No. M2180 Rain/dust cover Magnum Dolly

MovieTech-accessories-multi-adapter-steering-rod

Item No. 1029-1 Multi adapter (for steering rod)

MovieTech-accessories-seat-platform-mount

Item No. 1028-0 Seat or platform mount

MovieTech-accessories-low-platform-magnum-dolly

Item No. 1045-0 Low platform for Magnum Dolly

movietech-mitfahrplattform-2107-0-500x500px

Item No. 2107-0 Movietech ride platform

movietech-system-plattform-set-1036-01

Item No. 1036-01 Magnum system platform set (4 pcs.)

movietech-magnum-kombikugelschale-2030-0-500x500

Item No. 2030-0 Movietech Combi ball adapter

movietech-grip-accessories-dolly-seat

Item No. 2058-0 Movietech round seat for Dolly

movietech-säulenverlängerung-verstellbar-gasfeder

Item No. 2135-0 Riser adjustable 39-73cm

movietech-seitenschalen-2033-2034-2035

Item No. 2033 Off-Set ball adapter 150mm Short
Item No. 2034 Off-Set ball adapter 150mm Middle
Item No. 2035 Off-Set ball adapter 150mm Long

movietech-sitzarm-kombiniert-2051-2052-2053

Item No. 2051-0 Seat arm combined 10cm/4″
Item No. 2052-0 Seat arm combined 20cm/8″
Item No. 2053-0 Seat arm combined 30cm/12″

movietech-sitzarm-senkrech-2054-2055-2056-sitzarm-senkrecht

Item No. 2054-0 Seat arm vertical 10cm/4″
Item No. 2055-0 Seat arm vertical 20cm/8″
Item No. 2056-0 Seat arm vertical 30cm/12″

movietech-säulenverlängerung-2130-2131-2132-2133-2134

Item No. 2130-0 Riser 10cm/4″
Item No. 2131-0 Riser 20cm/8″
Item No. 2132-0 Riser 30cm/12″
Item No. 2133-0 Riser 40cm/16″
Item No. 2134-0 Riser 50cm/20″
